120mm2 Silicone Shielded EV Cable Wiring Harness with 1200A Current Rating

Name: 120mm2 Silicone Shielded EV Cable Wiring Harness with 1200A Current Rating
Brand: Linke
Price: 1 USD

Type 2 : XLPE Cable

HS Code : 94054090

Package Gross Weight : 25.000kg

specifications : 0.1-450mm²

insulating materials : customize:PVC、PE 、XLPE、EPR、SIR

Model NO. : silicone cable xlpe cable

Warranty : 1year

Trademark : LINKE

package : By roll

AMP : 1200A

After-sales Service : 1year

Currency : US$

rated temperature : -60± 200℃

Plug Type : IEC 62196-2 (Type 2), SAE J1772 Type 1

Transport Package : Roll

Lead Time : 7-15days

Return&refunds : You can apply for a refund up to 30 days after receipt of the products.

colour : customize

Type 1 : Silicone Rubber Cable

Supply Ability : 50000m/day

Size : 120mm2

Origin : China

Core : Multiple

Certification : 3C，UL，TPU，UL758，ROHS，REACH，CE，ISO9001-2015，ISO13485，IATF16949

Exterior material : customize：PVC、PE、LSFOH、silicone rubber

Color : Customized

Conductor Type : Twisted wire

Customization : Available

rated voltage : 300-600V

Place of Origin : Guangdong, China

Brand Name : Linke

MOQ : 1000m

Price : Negotiable

Packaging Details : According to requirement

Delivery Time : 7-15 days

Payment Terms : Advance 30% deposit and ship after receiving 70% final payment

Package Size : 800.00cm * 800.00cm * 580.00cm

conductor material : copper/Tinned Copper

type : insulated

Customized : Non-Customized

Samples : US$ 1000/PCS 1 PCS(Min.Order) |

Shipping Cost : about shipping cost and estimated delivery time.

: Initial Payment Full Payment

Contact Now

120mm² Voltage EV Cable Wiring Harness with Silicone Shielded Cable

Product Overview

High-quality booster jumper cables designed for automotive car jumping and power charging applications. These EV cables feature superior construction with silicone insulation for optimal performance and durability.

Cable Specifications

Model	Conductor (mm²)	Structure	Conductor DIA (mm)	Material	Insulation Thickness (mm)	Insulation Material	Insulation OD (mm)	20ºC Resistance (Ω/KM)
EV-YJ	1.5	48/0.20	1.60	Copper	0.6	Silicone	2.90±0.15	≤12.7
EV-YJ	2.5	80/0.20	2.06	Copper	0.7	Silicone	3.50±0.15	≤7.60
EV-YJ	4	128/0.20	2.62	Copper	0.8	Silicone	4.30±0.15	≤4.71
EV-YJ	6	196/0.20	3.50	Copper	0.8	Silicone	5.10±0.20	≤3.14
EV-YJ	10	322/0.20	4.50	Copper	1.00	Silicone	6.70±0.20	≤1.82
EV-YJ	16	513/0.20	5.70	Copper	1.10	Silicone	8.00±0.30	≤1.16
EV-YJ	25	798/0.20	7.10	Copper	1.3	Silicone	9.80±0.30	≤0.743
EV-YJ	35	1121/0.20	8.50	Copper	1.3	Silicone	11.40±0.30	≤0.527
EV-YJ	50	1596/0.20	10.10	Copper	1.50	Silicone	13.50±0.30	≤0.368
EV-YJ	70	2242/0.20	12.10	Copper	1.50	Silicone	15.50±0.40	≤0.259
EV-YJ	95	3034/0.20	14.10	Copper	1.50	Silicone	17.50±0.50	≤0.196

120mm2 Silicone Shielded EV Cable Wiring Harness with 1200A Current Rating

Brand	LINKE	Cross Section (mm²)	0.01-500mm²
Wire Gauge (AWG)	[e.g., 24AWG, 28AWG]	Conductor	Tinned Copper /bare copper, based on client's requirements
Insulation material	PVC/TPU/Silicone rubber/PE/PP/XLPE/Nylon/other	Jacket Material	[PVC/PU/Rubber/Braid/etc.]
Certifications	RoHS/REACH/UL/CE/IP68/etc	Custom Length	[e.g., 1m, 3ft, 5m ±5% tolerance]
Cable Type	[Medical/Power/Audio/Coaxial/Electrical/Automotive/Energy storage//etc.]	Shielding	[Shielded/Unshielded/Braid Shield]
Impedance	[e.g., 75Ω (for coaxial cables)]	Printing/Logo	[Text/Label/Logo, max. 20 characters]
Bend Radius	[e.g., ≥5* cable diameter]	Current Rating	[e.g., 5A]
Voltage Rating	[e.g., 30V AC/DC]	Connector Material	[Gold-plated/Nickel-plated/Brass/etc.]
Connectors	[e.g., USB Type-C, 3.5mm Jack, RJ45]	Jacket	XLPE or PE or PVC RUBBER
Delivery Time	7-14 days after confirming the order	Colors	[Black/White/Red/Custom Pantone/etc.]
temperature	Minus-70℃to 350℃(-70℃ ~ 350℃)	Package	Roll/box/plate/Custom
Supporting Services	custom cable, end to end solutions, including precise cutting, crimping and installation of lugs (specify material,e.g.,copper/nickel plated)

120mm2 Silicone Shielded EV Cable Wiring Harness with 1200A Current Rating

Quality Certifications

UL Standards: UL1007, UL1185, UL1672, UL10070, UL10483, UL1015, UL1569, UL10012, UL10269 (Single conductor, thermoplastic insulation)
Additional UL Certifications: UL2095, UL2129, UL2468, UL2586, UL2725, UL20233, UL20280, UL20963, UL2103, UL2463, UL2517, UL2587, UL2835, UL20276, UL20549, UL21198, 2104, UL2464, UL2576, UL2661, UL2919, UL20279, UL20886, UL21664
ISO9001 and ISO13485 Quality Management Systems
TS16949 Automotive Quality Standard
CNR Appliance Wiring Material Certification
Extruded PVC Insulated Single, rated 105ºC, 1000V, Class I, Group A, B, or AB, FT1 and/or FT2
Extruded PVC Non-integral Jacketed Cable, rated 105ºC, 1000V, Class I, Class or Class I/II, Group A, B, or AB, FT1 and/or FT2
Extruded TPU Non-integral Jacketed Cable, rated 80ºC, 300V, Class I, Class or Class I/II, Group A, B, or AB, FT1 and/or FT2

Frequently Asked Questions

Are you a manufacturer or trading company?

We are a professional manufacturer. We can control your order from the first beginning to the last. Welcome to visit us. We'll pick you up in Shenzhen.

How can I get a sample to test your quality?

The samples are free for you. New clients are expected to pay for the courier cost.

What's your Minimum Order Quantity?

Normally 100m. However, the cable is very heavy. You'd better order a suitable quantity to avoid the high freight. Sea transportation is the best option.

Can I get a discount?

It depends on your quantity. We can make a discount and afford the freight. Please kindly contact us.

Does your company accept OEM production?

Yes, we can print your company name, and we even customize the quality card to promote your company.
